Hauppauge Computer Works, or simply Hauppauge, is an U.S.-based vendor of multimedia PC devices.
Hauppauge derives its name from the hamlet in Suffolk county, New York (located on Long Island) within which the company is headquartered. Codenames used for the company's devices (as seen within Window driver INF files) are often drawn from the names of surrounding community areas on Long Island.
On October 29, 2008, Hauppauge purchased the Pinnacle PCTV product range and related assets from parent company Avid Technology, with the transaction expected to close before the end of Q4 2008. Hauppauge is apparently intending to continue to market the Pinnacle range of devices under the PCTV brand line.
Digital devices
Many of Hauppauge's early DVB-S and DVB-T products were actually rebranded TechnoTrend devices. This, however, is no longer the case today.
ATSC and ClearQAM products
| Model | Standard | Interface | Supported | Comments |
|---|---|---|---|---|
| WinTV-Aero-m | ATSC, ATSC-M/H, DVB-T | USB 2.0 | ✔ Yes | |
| WinTV-D | ATSC, NTSC | PCI | ~ Partial | Analog TV is supported, but digital TV is not. |
| WinTV-HD | ATSC | PCI | ✘ No | |
| WinTV-HVR-850 | ATSC, NTSC | USB 2.0 | ✔ Yes | Analog and digital "hybrid" stick; two versions exist -- essentially rebrands of the 950 & 950Q models |
| WinTV-HVR-950 | ATSC, NTSC | USB 2.0 | ✔ Yes | Analog and digital (ATSC-only) "hybrid" stick |
| WinTV-HVR-950Q | ATSC, ClearQAM, NTSC | USB 2.0 | ✔ Yes | Analog and digital "hybrid" stick |
| WinTV-HVR-955Q | ATSC, ClearQAM, NTSC | USB 2.0 | ✔ Yes | Analog and digital "hybrid" stick (digital only supported) |
| WinTV-HVR-1250 | ATSC, ClearQAM, NTSC | PCIe | ~ Partial | Digital TV is supported, but analog TV is not. |
| WinTV-HVR-1255 | ATSC, ClearQAM, NTSC | PCIe | ✘ No | |
| WinTV-HVR-1500 | ATSC, ClearQAM, NTSC | ExpressCard | ~ Partial | Digital TV is supported, but analog TV is not. |
| WinTV-HVR-1600 | ATSC, ClearQAM, NTSC | PCI | ✔ Yes | Analog and digital "combo" card |
| WinTV-HVR-1800 | ATSC, ClearQAM, NTSC | PCIe | ✔ Yes | Digital mode in recent kernels. Analog hardware MPEG encoder requires kernel 2.6.26 |
| WinTV-HVR-1850 | ATSC, ClearQAM, NTSC | PCIe | ✘ No | |
| WinTV-HVR-1950 | ATSC, ClearQAM, NTSC | USB 2.0 | ✔ Yes | |
| WinTV-HVR-2250 | ATSC, ClearQAM, NTSC | PCIe | ~ Partial | Digital TV is supported, but analog TV is not. |
| WinTV-HVR-2255 | ATSC, ClearQAM, NTSC | PCIe | ~ Partial | Digital TV is supported, but analog TV is not. |
| WinTV-quadHD | ATSC, ClearQAM | PCIe | ✔ Yes |
DVB products
| Model | Standard | Interface | Supported | Comments |
|---|---|---|---|---|
| DEC1100-T USB | DVB-T | USB 1.1 | ? Unknown | |
| DEC2000-T USB | DVB-T | USB 1.1 | ✔ Yes | Device with MPEG Decoder, can get used as standalone STB |
| DEC2540-T USB | DVB-T | USB 1.1 | ✔ Yes | Device with MPEG Decoder, can get used as standalone STB, decoder card slot not supported |
| DEC3000-S USB | DVB-S | USB 1.1 | ✔ Yes | Device with MPEG Decoder, can get used as standalone STB |
| WinTV-Duet-HD-Stick | DVB-T | USB 2.0 Stick | ✔ Yes | Bus powered |
| WinTV-HVR-900 | DVB-T | USB 2.0 Stick | ✔ Yes | Bus powered; more then one version (models 65008 & 65018) |
| WinTV-HVR-900H | DVB-T | USB 2.0 Stick | ✔ Yes | Bus powered; model number 66009, TM6010 based, no analog audio |
| WinTV-HVR-930 | DVB-T | USB 2.0 Stick | ✘ No | Bus powered; target market is France |
| WinTV-HVR-930C | DVB-T, DVB-C, PAL | USB 2.0 Stick | ✔ Yes | Analog and digital hybrid, initial support for USB ID 2040:1605 since 20111121.
(ID 2040:b130 is not supported - its retail box has HD in the name) |
| WinTV-HVR-930C-HD | DVB-T, DVB-C, PAL | USB 2.0 Stick | ✘ No | Analog and digital hybrid, USB ID 2040:b130 |
| WinTV-HVR-935 | DVB-T, DVB-T2, DVB-C, PAL | USB 2.0 Stick | ✘ No | Analog and digital hybrid, USB ID 2040:b151 |
| WinTV-HVR-935 HD | DVB-T, DVB-T2, DVB-C, PAL | USB 2.0 Stick | ~ Partial | Analog and digital hybrid, USB ID 2040:b151
Digital works with DVB-T and DVB-C. |
| WinTV-HVR-1100 | DVB-T | PCI | ✔ Yes | Analog and digital "hybrid" card (rectangular shape) |
| WinTV-HVR-1110 | DVB-T | PCI | ✔ Yes | Analog and digital "hybrid" card (triangular shape) |
| WinTV-HVR-1200 | DVB-T | PCIe | ~ Partial | Digital mode only currently |
| WinTV-HVR-1300 | DVB-T | PCI | ✔ Yes | Analog and digital "hybrid" card - features a hardware MPEG encoder |
| WinTV-HVR-1700 | DVB-T | PCIe | ~ Partial | Digital mode only currently |
| WinTV-HVR-1900 USB | DVB-T, PAL | USB 2.0 | ✔ Yes | Hybrid DVB-T USB device. |
| WinTV-HVR-2200 | DVB-T | PCIe | ~ Partial | Digital mode only currently |
| WinTV-HVR-2205 | DVB-T, DVB-T2, DVB-C | PCIe | ~ Partial | Digital mode only currently |
| WinTV-HVR-2215 | DVB-T, DVB-T2, DVB-C | PCIe | ~ Partial | Digital mode only currently |
| WinTV-HVR-3000 | DVB-T, DVB-S | PCI | ~ Partial | Digital requires kernel 2.6.28; analog support unknown. |
| WinTV-HVR-3300 | DVB-T, DVB-S | PCIe | ✘ No | |
| WinTV-HVR-4000 | DVB-T, DVB-S, DVB-S2 | PCI | ✔ Yes | |
| WinTV-HVR-4400 | DVB-T, DVB-S, DVB-S2 | PCIe | ✘ No | |
| WinTV-HVR-5500 | DVB-T, DVB-S, DVB-S2, DVB-C | PCIe | ✔ Yes | Only DVB-C/T (OOB) |
| WinTV-HVR-5525 | DVB-T, DVB-T2, DVB-S, DVB-S2, DVB-C | PCIe | ✔ Yes | |
| WinTV-Starburst2 | DVB-S, DVB-S2 | PCIe | ✔ Yes | PCIe ID 0070:f02a, uses DVB-S/S2 tuner of HVR-5525 |
| WinTV-quadHD | DVB-T, DVB-T2, DVB-C | PCIe | ✔ Yes | |
| WinTV-MiniStick | DVB-T | USB 2.0 | ✔ Yes | Tested on Debian Squeeze; works with firmware sms1xxx-hcw-55xxx-dvbt-02.fw |
| WinTV-NOVA-SE2 | DVB-S | PCI | ✔ Yes | |
| WinTV-NOVA-S PCI | DVB-S | PCI | ? Unknown | |
| WinTV-NOVA-S SE | DVB-S | PCI | ? Unknown | |
| WinTV-NOVA-S-Plus | DVB-S | PCI | ✔ Yes | |
| WinTV-NOVA-T-Stick | DVB-T | USB 2.0 Stick | ✔ Yes | Bus powered |
| WinTV-NOVA-TD-Stick | DVB-T | USB 2.0 Stick | ✔ Yes | Bus powered |
| WinTV-NOVA-T-CE-Stick | DVB-T | USB 2.0 Stick | ? Unknown | Bus powered; target market is Germany |
| WinTV-NOVA-T-USB2 | DVB-T | USB 2.0 | ✔ Yes | Bus powered |
| WinTV-NOVA-CI PCI | DVB-S | PCI | ? Unknown | Card with optional CI-Interface |
| WinTV-NOVA-C PCI | DVB-C | PCI | ? Unknown | |
| WinTV-NOVA-T PCI | DVB-T | PCI | ✔ Yes | |
| WinTV-NOVA-T-500 | DVB-T | PCI | ✔ Yes | Dual tuner card whose receivers are actually USB based |
| WinTV-NOVA-TD-500 | DVB-T | PCI | ✘ No | Dual tuner card whose receivers are actually USB based |
| WinTV-NEXUS-S Rev. 2.1 | DVB-S | PCI | ? Unknown | Card with optional CI interface module |
| WinTV-NEXUS-S Rev. 2.2 | DVB-S | PCI | ? Unknown | Card with optional CI interface module |
| WinTV-NEXUS-S Rev. 2.3 | DVB-S | PCI | ? Unknown | Card with optional CI interface module |
| WinTV-NOVA-S USB | DVB-S | USB 1.1 | ✔ Yes | |
| WinTV-NOVA-S-USB2 | DVB-S | USB 2.0 | ✘ No | |
| WinTV-NOVA-HD-S2 | DVB-S2 | PCI | ? Unknown | |
| WinTV-NOVA-HD-USB2 | DVB-S2 | USB 2.0 | ✘ No | |
| WinTV-NOVA-T USB | DVB-T | USB 1.1 | ✔ Yes | |
| WinTV-dualHD | DVB-T, DVB-T2, DVB-C | USB 2.0 | ✔ Yes | Both tuners work at the same time. Bus powered |
| WinTV-soloHD | DVB-T, DVB-T2, DVB-C | USB 2.0 | ✔ Yes | Bus powered |
Analog devices
| Model | Standard | Interface | Supported | Comments |
|---|---|---|---|---|
| ImpactVCB | Video | PCI | ? Unknown1 | No tuners, only video-in, based on Fusion 878A |
| ImpactVCB-e | Video | PCIe | ✔ Yes | No tuners, only video-in. S-Video capture works with kernel 3.5.0 (Ubuntu 12.10). |
| USB-Live | NTSC/PAL | USB | ? Unknown | Software encoder |
| WINTV PAL-B/G 38104 REV.B208 | PAL | PCI | ✔ Yes | Software encoder |
| WinTV PAL-B/GI 61314 REV B1M | PAL | PCI | ✔ Yes | Software encoder |
| WinTV-GO-FM | NTSC/PAL | PCI | ? Unknown | Software encoder |
| WinTV-GO-Plus | NTSC/PAL | PCI | ? Unknown | Software encoder |
| WinTV-PCI-FM | PAL/SECAM | PCI | ✔ Yes | One tuner |
| WinTV-PVR-150 | NTSC/PAL | PCI | ✔ Yes | One tuner, MPEG2 hardware encoder |
| WinTV-PVR-250 | NTSC/PAL | PCI | ✔ Yes | One tuner, MPEG2 hardware encoder |
| WinTV-PVR-350 | NTSC/PAL | PCI | ✔ Yes | One tuner, MPEG2 hardware encoder and decoder |
| WinTV-PVR-500 | NTSC/PAL | PCI | ✔ Yes | Two tuners |
| WinTV-PVR-USB2 | NTSC, PAL | USB | ✔ Yes | MPEG2 hardware encoder and decoder |
| WinTV-Radio | NTSC/PAL | PCI | ? Unknown | Software encoder |
| WinTV-USB | NTSC/PAL | USB | ? Unknown | Software encoder |
| WinTV-USB-FM | NTSC/PAL | USB | ? Unknown | Software encoder |
| WinTV-USB2 | NTSC/PAL | USB | ? Unknown | Software encoder |
1 Hauppauge says "a public domain Linux driver is also available for the ImpactVCB" in page http://www.hauppauge.com/site/products/data_impactvcb.html (at section 'System requirements' > 'Hardware requirements'). Hauppauge may speak about the bttv kernel driver supporting the Conexant Fusion 878A...
- Hauppauge WINTV DBX TV Stereo 125CHNL TV Tuner w/FM Stereo Radio PCI -- [writeup in Linux Journal]
- Hauppauge WinTV USB 2
Analog video grabbing
- Impact VCB (Model 64XXX) 00558
- USB-Live (Model 403XX) 00609
Analog TV viewing
- WinTV Express (Model 44XXX) 00751
- WinTV GO 2 (Model 347XX) 00750
- WinTV PCI-FM (Model 345XX) 00718
- WinTV USB (Model 402XX) 00569
- Supported by the USBVision driver
- WinTV USB-FM (Model 402XX) 00568
- WinTV USB2 (Model 420XX) 01017
- Supported by the em28xx driver
Personal video recording
- WinTV PVR-USB2 (Model 24xxx) 00960
- WinTV PVR-150 (Model 26xxx) 01048
- WinTV PVR-350 (Model 48xxx) 00991
- WinTV PVR-500 (Model 23xxx) 01072
- HD PVR ... MythTV page
Music, video, picture
- MediaMVP (Model 86xxx) 01005
- Wireless MediaMVP (Model 86xxx) 01133
Model synopsis and internal names
BT848 based boards have the following Model numbers: 56XXX Mattituck WinCast 58XXX "Little Mattituc" WinTv analogue 60XXX "Plum Island" EuroCast BT878 based boards have the following Model numbers: 64xxx Capture only (Impact VCB) 61xxx "Robins Island" 44xxx Neptune 39xxx Bridgehampton (WinTV-D ?) 38xxx Orient Point 37xxx Aquebogue WinTV Theatre CX23881 based boards have the following Model numbers: 34xxx Pluto 33xxx ????
Model 14xxx: WinTV-HVR-3000
Model 23xxx: Amity2DT PVR500-MCE (WinTV-PVR-500)
Model 24xxx: WinTV-PVR-USB2 (see also 29xxx)
Model 25xxx: Baldwin2 (low profile) PVR150LP-MCE
Model 26xxx: Amity2 PVR150-MCE
260xx: WinTV PVR-150 Retail (no radio, with IR, no Audio RCA)
265xx: WinTV PCR-150 MCE (and OEM) (with radio, no IR, with Audio RCA)
Model 28xxx: Roslyn, OEM only ! (follows Conexant Blackbird reference Design)
This card has sometimes been incorrectly called the "PVR-250MCE". It has no official name other than its codename: "Rosyln
In US it was also sold as PVR-160 (by Fry electronics and others...)
Model 29xxx: Dering Harbor WinTV PVR USB2 /Retail (see also 24xxx)
Model 30xxx: Baldwin1 or "Baldwin Harbor" (PVR 250 MCE LP)
Model 32xxx: Amity1 or "Amity Harbor" WinTV PVR 250 /Retail (32059 MultiPAL, 32065 PAL B/G)
320xx: WinTV PVR 250 (no Radio, with IR, no RCA Audio)
325xx: WinTV PVR 250 MCE (or OEM or Freestyle) (with Radio, no IR, with Audio RCA)
Model 39xxx: WinTV-D
Model 40xxx: Waterville WinTV USB /USB FM/ MyTV2Go (Mac)
Model 42xxx: Deltron WinTV USB2
Model 43xxx: Uranus WinTV PVR USB
Model 45xxx: "Solo Jr." WinTV PVR PCI (with Kfir chip)
Model 46xxx: WinTV HD (ATSC/NTSC)
Model 47xxx: WinTV-Nova-S-USB2
Model 48xxx: Sag Harbor
Model 480xx: PVR 250 ?? (without saa7127, no tv out)
Model 481xx: PVR 350 ?? (with saa7127, with tv out)
Model 484xx: OEM Freestyle aka PVR 250 MCE( white and red audio r+l rca jacks)
Model 64xxx: New Suffolk Impact VCB
Model 65xxx: 65008, 65018: WinTV-HVR-900 (EM2880) / 65009, 65019: Win-TV-HVR-930 (France)
65201 WinTV-HVR-950 (USA)
Model 66xxx: 66009 WinTV-HVR-900H (TM6010, no analoge audio!)
Model 67xxx: WinTV-HVR-1110 (France?)
Model 69xxx: 69009 WinTV-HVR-4000 /69100 WinTV-Nova-HD-S2 / 69500 WinTV-Nova-S2-HD
Model 69100/69500: WinTV-Nova-HD-S2 (DVB-S2)
Model 70xxx: WinTV-Nova-T-Stick
Model 71xxx: WinTV-HVR-1200 (OEM only?)
Model 74xxx: WinTV-HVR-1600
Model 75xxx; WinTV-HVR-1500
Model 76xxx: WinTV-HVR-1800LP
Model 78xxx: WinTV-HVR-1800
Model 79xxx: WinTV-HVR-1250
Model 86xxx: "Video Dongle" MVP / MediaMVP
Model 90xxx: Chelsea WinTV-Nova-T PCI (after August 2004)
Model 90501: (UHF/VHF),
Model 90500: (UHF) Nova-T MCE Chelsea DVB-T
Model 92xxx: Bremman 92001 WinTV-Nova-S-Plus / 92500 WinTV-Nova-SE2 (only DVB-S connector, no other connectors)
Model 93xxx: WinTV-Nova-T USB2
Model 94xxx: WinTV-HVR-1100 (Oxford)
Model 95xxx: 95809 WinTV-Nova-TD-Stick
Model 96xxx: WinTV-HVR-1300 (Dover)
Model 98xxx: WinTV-HVR-1100 LP (Oxford HH)
Model 99xxx: WinTV-Nova-T-500
Model 150300: WinTV-Starburst2 (pci-e 0070:f02a)
Some Cards are OEM Technotrend cards and don't have Model numbers: (mappings from http://www.dvbshop.net/media/products/0741593001144144930.pdf) WinTV-Nova-S-PCI (=TT Budget 1500) WinTV-Nova-S-USB (=TT Connect S1810) WinTV-Nova-SE PCI(= TT BudgetS1400) WinTV-Nova-CI-S PCI WinTV-Nova-T (TT Budget) [Note: this is a different card from WinTV-Nova-T-PCI !) WinTV-Nova-T-USB (Connect T1900) WinTV-Nova-C-SUB (Connect C1100) WinTV-Nexus-S (=TT Premium 2300) WinTV-Nexus-CA (=TT Premium C2300 ???) ...
Notes
- MCE boards have no IR, but use the bracket space for RCA Audio (R+L)
- The term "Freestyle" is often used for OEM non-Retail versions of the cards. These are MCE cards technically.
- Sometimes OEM cards have FM radio (whereas the retail cards lack this).
WinTV-NOVA
Hauppauge uses the WinTV-NOVA moniker for their digital TV PCI cards that lack an onboard MPEG-2 decoder (i.e. the designation is used for their so-called "budget" or software decoding cards). The -C, -S or -T suffices respectively signify whether the device is intended for DVB-C, DVB-S or DVB-T reception.
WinTV-NEXUS
Hauppauge used the WinTV-NEXUS moniker for digital TV PCI cards that included an onboard MPEG-2 decoder; these were rebranded Technotrend SkyStar 1.x full-featured cards to which a second PCI card could be interconnected to provide hardware support for Common Interface subscription-TV modules.
WinTV-HVR
The WinTV-HVR moniker is used for Hauppauge's hybrid line of devices (i.e. they feature both analog and digital tuning capabilities). The "HVR" stands for Hybrid Video Recorder.
